The MAX6351–MAX6360 microprocessor (µP) supervisors with multiple reset voltages significantly improve system reliability and accuracy compared to separate ICs or discrete components. If any input supply voltage drops below its associated preset threshold, all reset outputs are asserted. In addition, the outputs are valid as long as either input supply voltage remains greater than +1.0V. All devices in this series have an active-low debounced manual reset input. In addition, the MAX6358/MAX6359/ MAX6360 offer a watchdog-timer input with a 46.4s startup timeout period and a 2.9s timeout period. The MAX6355/MAX6356/MAX6357 offer an additional voltage monitor input to monitor a third voltage. The MAX6351 features two active-low, push-pull reset outputs, one is referenced to V CC1 and the other is referenced CC2. The MAX6353/MAX6356/MAX6359 offer an active-low, push-pull reset output referenced to V The MAX6354/MAX6357/MAX6360 offer an active-low, push-pull reset output referenced to V All these devices are offered with a wide variety of voltage threshold levels, as shown in the table. They are available in 5- and 6-pin SOT23 packages and operate over the extended (-40°C to Precision Monitoring of Multiple +1.8V, +2.5V, +3.0V, +3.3V, and +5V Power-Supply Voltages Precision Factory-Set Power-Supply 100ms min Power-On Reset Pulse Width Fully Guaranteed Over Temperature Guaranteed RESET Valid to VCC1 = 1V or Power-Supply Transient Immunity No External Components for Dual-Voltage Small 5- and 6-Pin SOT23 Packages Be sure to add me to your favorites list! (We do not proofread any ads submitted by members) |
