Tektronix 475 Service Manual S/N 249,999-Dn (070-1332-00), plus 475 Service Manual S/N 250,000-Up (070-1862-00), plus DM-44 Service Manual (070-2036-01), DM43/DM40 Service Manual (070-1779-00), 475/DM44 Operator's Manual (070-2039-00) and 1106 (DC Supply) Service/Op Manual (070-1713-00) NOTE: NONE of the above listed are Military Manuals! (However, we DO throw in the five military manuals that "marketers" "include in their volume counts") For High Res page samples from this specific manual (475 Low Serials - all others are single res), click HERE. (No need to "email for samples," so no need to worry about getting sold to a SPAM list!) (Please read FAQ or "About Me" Page) This manual set covers maintenance, servicing and operation of ALL serial numbers of the Tektronix 475 Oscilloscope. Serial numbers B249999 and below are provided in our extremely popular "dual resolutions", and the others are provided in single res PDFs. They are all scanned from the original manufacturer's manuals. The scans came out well, and all information available in the original manuals is available here. SCAN PARAMETERS of the Very High Res 475 Lo Serials (to 250000) PDF: Text with photos: 600dpi grayscale (contrast adjusted) Text with Drawings: 600dpi black and white Schematics: 600dpi black and white Schematics and board overlays with color notes: 400-600dpi 24M colors Fully Bookmarked and Hyperlinked Chapter-Page -AND- Sequential Page Numbering Scan parameters of the standard res PDFs (a second scan of the 475 Lo S/N Manual plus the other manuals described below are done in this faster, less resource intensive resolution): The standard res PDFs are done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. They are also text-searchable! All original manual pages are supplied, with no pages added or subtracted (NO shareware begging pages! NO logos on every page! NO fake copyrights on schematics!) Along with the 475 Service Manuals and the Operating Manual are the full service manuals for the DM44 multimeter accessory and also the DM43/DM40 multimeter accessory (the DM43 and DM40 are covered in a single manual), as well as the 1106 battery pack. As stated above, these are provided in our fast, text-searchable standard resolution. We also threw in the five freely downloadable redundant military manuals "marketers" trick up their "volume counts" with. NO, we did NOT include them in our "volume count"! Please read our FAQ. (We do not proofread any ads submitted by members) |
