MM5316 Digital Alarm Clock IC - NEW The MM5316 digital alarm clock is a monolithic MOS integrated circuit utilizing P-channel low threshold, enhancement mode and ion-implanted depletion mode devices. It provides all the logic required to build several types of clocks and timers. Four display modes (time, seconds, alarm and sleep) are provided to optimize circuit utility. The circuit interfaces directly with 7-segment fluorescent tubes, and requires only a single power supply. The time keeping function operates from either a 50 or 60 Hz input, and the display format may be either 12 hours (with leading-zero blanking and AM/PM indication) or 24 hours. Outputs consist of display drives, sleep and alarm enable. Power failure indication is provided to inform the user that incorrect time is being displayed. Setting the time cancels this indication. The device operates over a power supply range of 8-29 V and does not require a regulated supply. The MM5316 is packaged in a 40-lead dual-in-line package. There are several additional pages of documentation that are provided with purchase. See pictures for additional details. **** DO NOT USE "ASK SELLER A QUESTION LINK" TO CORRESPOND WITH ME. **** I AM MORE THAN HAPPY TO ANSWER ANY QUESTIONS! YOU MAY EMAIL ME DIRECTLY USING: e-jennings@desmoines-classifieds.com ************************************************************************************************************* ************************************************************************************************************* ************************************************************************************************************* ************************************************************************************************************* This Ad created with The Poster Toaster. (We do not proofread any ads submitted by members) |
