PINES 2 HYDRAULIC ROTARY TUBE BENDER* Maximum Tube Radius: 20" Maximum Tube Length Over Mandrel: 7'5" Average Maximum Bending Arm Speed: 5.5 RPM; Speed Control Valve Standard Operating Pressure: 2,000 PSI Counter-Clockwise Rotation EQUIPPED WITH: Automatic Hydraulic Mandrel Extractor Pressure & Clamp Die Holders AC Main (Pump) Drive Motor; Electrical Controls Pedestal Mounted Multiple Push Button Operation Bijur Automatic Slide Lubrication System; Swinging Arm Safety Device BENDING CAPACITIES: I.P.S. Extra Heavy Pipe: 2" Non-Ferrous Tubing Y.P. to 12,000 PSI: 3-1/2" O.D. x .188" Wall Non-Ferrous Tubing Y.P. to 25,000 PSI: 3-1/2" O.D. x .120" Wall Steel Tubing Y.P. to 40,000 PSI: 3-1/2" O.D. x .083" Wall Stainless Steel Tubing Y.P. to 60,000 PSI: 3" O.D. x .065" Wall Steel Bar Round Y.P. to 40,000 PSI: 1-7/8" Diameter Steel Bar Square Y.P. to 40,000 PSI: 1-11/16" Square Angle Iron Y.P. to 40,000 PSI: 3" x 3" x 5/16" Square Tubing Mild Steel: 2-1/2" x .083" Rectangular Tubing Mild Steel (E-Plane): 1-1/2" x 3" x .148" Rectangular Tubing Mild Steel (H-Plane): 1-1/2" x 2-1/2" x .120" Approximate Overall Dimensions: 144" L-R x 50" F-B x 45" H Approximate Weight: 4,500 Lbs. Serial Number: 11290-85208 (New 1985) P2 F.O.B. Elk Grove, IL - $ 31,500.00 * PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION Email us at Gilbertnavarro@desmoines-classifieds.com Call our Sales Staff at 1-(***)-254-8808 Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes. Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power. 1-(***)-427-3333 (outside US & Canada) Email: Gilbertnavarro@desmoines-classifieds.com (We do not proofread any ads submitted by members) |
