• Controls oil burner, oil valve (if desired) and the ignition transformer in response to a call for heat • Solid state flame sensing circuit • LED on terminal strip indicates system lockout • Enclosed safety switch with external reset button • Mounts on standard 4 x 4 in. junction box; select models may be mounted directly on burner housing • C554A Cadmium Sulfide Flame Detector and 24 VAC thermostat required • Direct replacement for popular competitive models. Ignition Type Intermittent: Timing, Safety Switch • 15 seconds. Mounting Bracket • For mounting on a standard 4†X 4†junction box or direct mounting on burner housing Electrical Rating; Contacts (full load) • 7.4 A @ 120 VAC; 3.7 A @ 240 VAC Electrical Rating; Contacts (locked rotor) • 44.4 A @ 120 VAC; 22.2 A @ 240 VAC Dimensions •4 3/8 in. high x 4 1/8 in. wide x 2 1/2 in. deep • 111 mm high x 104mm wide x 64mm deep. Temperature Range • -30°F to +130°F. Approvals • Underwriters Laboratories Inc. REPLACES- HONEYWELL: R8184G4066, R8184G1161, R8184G1294, WHITE RODGERS 668-601 (SAFTEY TIMING 15 SECONDS). ICM ICM1501 (We do not proofread any ads submitted by members) |
