Tektronix 7613 Service Manual Plus Sixty One 7000-Series Plugin (for 54 Plug-Ins) Manuals in PDF in a 2-CD Set ->Standard Res Samples<-(7613 & Plugins) For page samples from the specific Reproduction Grade manual (7613) included, click HERE. (No need to "email for samples," so no need to worry about getting sold to a SPAM list!) (Please read FAQ or "About Me" Page) These manuals cover the Tektronix Model 7613 oscilloscope frame plus a substantial number of plugins (see list below). They are all scanned from the original Tektronix commercial manuals. The scans came out well, and all information available in the original manuals is available here. Two PDFs of the Oscilloscope Mainframe Service Manual are provided, in two resolutions. One is: Text with Drawings at 600dpi black and white Schematics at 600dpi black and white Text with photos at 600dpi grayscale with contrast adjusted Any Schematics, board overlays with color notes at 600dpi 256 colors The second 'Scope Mainframe Service Manual scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. Here's a listing of the plugin manuals included. This is not a choice of manuals, you get them ALL! As a "bonus", includes the Tektronix publication "Tektronix 7000 Series Digital Plug-in Applications" (time and frequency, digital delay, amplitude, temperature) at no additional charge. Please note that this is not included in the "volume count". (We do not proofread any ads submitted by members) |
