3 HP Variable Speed Spindle Motor Table Dimensions (Overall), W x L...... 9" x 42" Table Longitudinal Travel (X-Axis)..... 26" Saddle Cross Travel (Y-Axis)........... 16" Knee Vertical Travel (Z-Axis).......... 16" Ram Travel............................. 22.19" Quill Travel........................... 5" Spindle-Center To Body, Minimum........ 2.31" Spindle-Center To Body, Maximum........ 30.5" Spindle-Nose To Table, Maximum......... 18.5" Quill, Diameter........................ 3.375" Spindle Taper.......................... #R8 Spindle Speeds, Range.................. 54 to 4500 RPM Quill Feeds, Range..................... .003 to .006 IPR Spindle Motor, Horsepower/RPM.......... 3 HP/1730 RPM Electrical System...................... 220-440/3/60 Floor Space Required, W x D............ 5' x 4'11" Overall Height......................... 5'10" Weight, Approximately.................. 2550 LBS PRICE: F.O.B. OUR WAREHOUSE........... $4,950.00 All machines/equipment subject to prior sale. (We do not proofread any ads submitted by members) |
billieharmon@desmoines-classifieds.com (Billie Harmon) for more information. Your emails will be instantly forwarded to the poster's private address.
