DIGITAL MULTISTANDARD VIDEO DECODER CHIP USES A SINGLE FREQUENCY 24.576MHz CRYSTAL FOR IT'S CLOCK BRAND NEW PARTS WHICH ARE BULK PACKED IN ESD SAFE BAG USED IN VIDEO CAPTURE CARDS, SCAN CONVERTERS, NTSC <-> PAL CONVERTERS SELLING 1-50 10PC LOTS SEPERATLY! UP FOR SALE ARE 1-50 PHILIPS CORPORATION SAA9051WP 68-PIN PLCC PKG'D DIGITAL MULTISTANDARD VIDEO DECODER IC. THESE WILL TAKE EITHER A COMPOSITE VIDEO OR S-VIDEO SIGNAL INPUT AND DECODE IT INTO RGB SIGNALS ALONG WITH THE OTHER NEEDED DATA. THEY ARE NORMALLY USED WITH THIER COMPANION CHIP THE SAA9057A WHICH FUNCTIONS AT THE SAA9051'S TIMING GENERATOR WHICH GIVES THE SAA9051 ALL IT'S NEEDED TIMING SIGNALS. THESE CHIPS CAN EITHER BE SOLDERED TO OR PLUGGED INTO A 68-PIN PLCC SOCKET. THESE HAVE BEEN AROUND FOR A LONG WHILE AND ARE PRETTY EASY TO PROGRAM AND USE. ONCE THE COMMANDS ARE SENT TO IT, IT TAKES IT FROM THERE AND JUST DOES AS IT WAS TOLD. SO ONCE YOU HAVE PUT THE CORRECT DATA INTO EACH OF IT'S COMMAND REGISTERS YOU ARE DONE. YOU JUST SIT BACK AND ENJOY THE WITH THIS IC PLUS IT'S COMPANION TIMING GENERATOR IC THE SAA9057A YOU HAVE A COMPLETE MULTISTANDARD VIDEO DECODER BUT THEN IF YOU ADD SOME SERIAL DUAL PORT VIDEO MEMORY TO IT'S OUTPUT AND THE ADDON A MULTISTANDARD VIDEO ENCODER YOU CAN CONVERT A PAL SIGNAL TO A NTSC SIGNAL OR CONVERT A NTSC SIGNAL TO A SECAM SIGNAL AND SO FORTH AND SO ON. GET THE POINT! ALSO ONE CAN CAPTURE ONE FRAME OF VIDEO INTO MEMORY THEN CONVERT IT TO A JPEG PICTURE FORMAT FILE AND STORE IT ON YOUR COMPUTER'S HARD DRIVE. I AM NOT SAYING IT IS EASY BUT IT CAN BE DONE AS A FRIEND OF MINE HAS ALREADY DONE SO A FEW YEARS BACK. ** REMEMBER TO RENAME THE PDF FILE TO WHATEVER NAME YOU WANT OR CAN REMEMBER! ** SAA9051WP DATASHEET SOLD GUARANTEED TO BE NEW & UNUSED PRODUCT!. THANKS FOR LOOKING AND GOOD LUCK! Please look at my other items for sale! (We do not proofread any ads submitted by members) |
