FS-V20 Series Digital Display Amplifier 250μs (FINE)/500μs (TURBO)/1ms (SUPER TURBO)/4ms(ULTRA TURBO)/ 500μs (HIGH RESOLUTION)/50μs (HIGH SPEED) Light-ON/Dark-ON (switch-selectable) Light intensity/rising edge/falling edge Mode:Timer OFF/OFF-delay timer/ON-delay timer/One-shot timer, selectable Variable range:1 to 500ms [1 to 30ms (in 1ms increments), 30 to 50ms (in 2ms increments), 50 to 200ms (in 10ms increments), 200 to 500ms (in 50ms increments)] Accuracy:±10% of the Preset Value NPN or PNP 100 mA max. (40VDC max), Residual voltage : 1Vmax. 12 to 24VDC ±10% , ripple: 10% max. Incandescent lamp: 20,000 lux max. , Sunlight: 30,000 lux max. -10°C to +55°C (14 to 131°F), No condensation 10 to 55 Hz, 1.5-mm double amplitude, each in X, Y, and Z directions for two hours 500 m/s² Three times each in X, Y, and Z directions (We do not proofread any ads submitted by members) |
