EZ LG OS-5030 30MHz 2-Channel Oscilloscope O-Scope * DC to 20MHz bandwidth, 2 channels, Dual trace * 6" rectangular CRT with internal graticule * ALT triggering function in VERT mode * CH2 polarity inversion switch * High sensitivity X-Y mode * Sweep magnification (X 10) * TV sync. Separator circuit for stable TV signal observation * 400V maximum input voltage Configuration and useful screen 6-inch rectangular screen with internal graticule: 8X10 Div (1 div=1cm). marking for measurement of rise time 2mm subdivisions along the central axis. Z-AXIS INPUT (INTENSITY MODULATION) Positive going signal decreases intensity +5Vp-p or more signal cases noticeable modulation at normal intensity settings. DC to 20MHz normal / DC to 10MHz magnified (CH1 only) 10Hz to 20MHz normal / 10Hz to 10MHz magnified (CH1 only) CH1,CH2,ADD,DUAL (CHOP; Time/div switch -0.2s to 1mS, ALT ; Time/div switch -0.5mS to 0.2µS) 5mV/div to 5V/div in 10 calibrated steps of a 1-2-5 sequence. Continuously variable between steps at least 1:2.5 x5 MAG ; 1mV/div to 1V/div in 10 calibrated steps. (CH1 only) 50mv/div to 50V/div (with 10:1 Probe used) normal; ±3%, magnified:±5% (CH1 only) approx. 1MW in parallel with 30pF Direct; 250V(DC+peak AC), with probe; refer to probe specification 17.5nS or less (35nS or less; x5 MAG) 25mV/div into 50W ; DC to 10MHz (-3dB) 0.2us/div to 0.2S/div in 19 calibrated steps, 1-2-5 sequence. uncalibrated continuous control between steps at least 1:2.5 10 times (maximum sweep rate ; 20nS/div) ±3%, ±5% (0°C to 40°C), additional error for magnifier ±2% Note: 50nS/div, 20nS/div (±10%) External trigger input impedance (same as CH1 except for the following) Deflection factor ; same as that of CH1 / Accuracy ; ±5% / Frequency response ; DC to 500KHz (-3dB) approx. 1KHz frequency (±20%), 0.5V (±10%) square wave duty ratio; 40-50% 316mm (W) X 143mm (H) x 406mm (L) If you require more detailed specifications, please contact the manufacturer for technical support. (Worldwide including Hawaii, Alaska, Canada) This warranty excludes consumable goods. Consumable goods are not guaranteed to come with the item unless otherwise noted in the item description. Consumable goods includes: toner, ink cartridges, bulbs, and batteries. All California residents will be charged CA sales tax during the Checkout process. Please click on the links below for answers frequently asked questions about that category. Questions? Check out our Frequently Asked Questions page for detailed answers. Request for return merchandise authorization (RMA) Call us. (Monday-Friday 10AM-6PM PST) Mailing address for money orders and checks Tel: (***) 757-3863 (Toll Free) (We do not proofread any ads submitted by members) |
