TRAVELS................................(X)22.05" ................................(Y)16.14" ................................(Z)18.11" DISTANCE SPINDLE NOSE TO TABLE TOP.....5.91"~24.02" THROAT DEPTH...........................23.11" TABLE SIZE.............................35.43" X 16.14" TABLE LOAD CAPACITY....................1100 lbs SPINDLE SPEED RANGE....................60~7000 RPM SPINDLE TAPER..........................CAT 40 RAPID TRAVERSE RATE....................(X/Y)945 IPM ....................(Z)590 IPM CUTTING FEED RATE......................0.04~315 IPM TOOL CAPACITY..........................24 TOOL CHANGE TIME.......................1.6s SPINDLE MOTOR..........................7.5/10 HP ELECTRICAL REQUIREMENT.................21.4 kVA MACHINE DIMENSIONS (APPROX)............114.84" X 76.38" MACHINE WEIGHT (APPROX)................10,600 lbs 4th AXIS READY (ROTARY TABLE NOT INCLUDED) (We do not proofread any ads submitted by members) |
Jean.Freeman@desmoines-classifieds.com (Jean Freeman) for more information. Your emails will be instantly forwarded to the poster's private address.
