Available in 5 inch (129 mm), 6 inch (154 mm) and 8 inch (203 mm) diameters to accommodate wafers up to 200mm in diameter. Choice of gold-plated or nickel-plated is standard (Other optional surface treatments are available by contacting Temptronic) Wide Temperature range: 0° to +200°C DC Control System minimizes electrical noise Temperature Stability :±0.1°C Temperature Accuracy: ±0.5°C calibrated against transfer standard Advanced ThermoChuck Design: Low stray capacitance and high electrical resistance to ground: Surface Electrical Isolation: >109 ohms at 500 VDC between surface and ground at +25°C ; higher isolation configurations are available Superior chuck temperature uniformity: ±0.5°C or ±0.5% of set temperature Guarded ( low leakage) chuck configurations are optional IEEE-488 or RS232 remote interface ThermoChuck interfaces to most major standard and automatic wafer probing stations, laser trimmers and inspection stations No Liquid Nitrogen or CO2 is required for cooling. Thermal cycling and steady- state thermal testing of wafers, hybrids and other flat devices from 0°C to +200°C Moisture-free cold testing of wafers to 0°C with Controlled Environment Enclosure Low noise test applications High isolation and guarded ( low leakage) applications Thermal characterization of standard and high power devices SURPLUS REMOVED FROM SEMIFAB MFG/TEST FACILITY. NOT SURE IT WAS EVER USED, LOOKS NEW. STILL CRATED. COMES AS PICTURED. PLEASE FEEL FREE TO ASK QUESTIONS. UNIT WILL BE PALLETIZED AND READY FOR DOCK-HIGH PICKUP FROM AREA CODE 75074 we reserve the right to re-list the item if not paid after 7 days. IF YOU ARE IN ALASKA OR HAWAII PLEASE BE PREPARED TO PAY A SLIGHTLY Seller is not responsible for uninsured items. Texas residents add 8.25% Sales Tax. This Item is represented as accurately as possible. (We do not proofread any ads submitted by members) |
